Horizontal Decanter 2 Phase Titanium Separator - Centrifuge 3~15m3/h

Model PDC Titanium Separator - Centrifuge Horizontal Decanter Centrifuge for Calcium Sulfate

 Quick skimming

Application:

1. Salt chemical industry
2. Calcium hypochlorite

3. Material with high content of Cl-

Decanter design

Type: 2-phase separation
Material: titanium for all wet parts
Bearing: SKF brand. A special selection and arrangement of bearings provides for long life and exceptional reliability
Wear protection: welded hard facing or spray coating, ceramic technology

Working principle

The drum and the spiral feeder rotate in the same direction but with a certain speed difference; the material is led into the feeding spiral inner cylinder via the feeding pipe and, after speeding pipe and, after speeding up, enters the drum; under the action of the centrifugal force field, the relatively heavier solid-phase material deposits on the drum wall forming the residue layer;

the solid-phase residue is continuously pushed by the spiral feeder to the conic end of the drum and, after dehydration in the drying area, is discharged out of the machine. The machine is capable of continuous feeding, separating, dehydrating and discharging under full-speed running.

Basic principles

For the decanter centrifuge, the continuous feeding, separating and discharging can be realized as it rotates at its full speed. It is characterized by compact structure, easy obturation, smooth running, low noises, large handling capacity, low energy consumption, high automation, small working strength, simple operation and easy maintenance, and wide applications.

Structure



Technical parameters


PS: The above parameters will be subject to the final technical agreement.
